Agricultural Chain


 Since some of NZ largest industries are agricultural based we carry a wide range of chains to suit many different machines
Argicultural chains and sprockets are definitely no problem for us at SprocketsNZ


One of the more common chains are the "S" type steel agricultural chains.
The "S" type steel agricultural chains have a wasted side plate and are often seen on seed drills, harvestering equipment and elevators.  We not only carry it in a standard chain but also in Zinc plated to withstand some of the weather conditions that agricultural machines are left out in.  It has also become common to replace the cast detachable chain with one of the 'S" series chains.
Along with the plain chain we also carry a vast range of K1 or A1 attachment con links.  These con links are useful when it comes to scrapper bars or specific attachments bolted to the chain for harvesting etc.


S Type chain S Type ag chain.pdf (367 KB)

"CA" type steel agricultural chains are the next most common agricultural chain.  With a straight heavy side plate, it is often used in the harvesting or fertilizing industry.  CA550 and CA557 are the most common option in the "CA" chains.
We also carry a range of attachments for this chain.  Please do not hesitate to get in touch with any abnormal enquiry.


CA Type Chain CA type chain.pdf (302 KB)
Other agricultural chains can include but are not limited to:

  • Transmission roller chains such as HSP (Heavy Super Power) which has an additional 25% - 30% greater ultimate tensile strength by using hardened pins.
  • Double pitch conveyor chain such as C2050, C2060 or C2080
  • Steel pintle chain (667X, 667H, 667K or 88K)
  • Combination chain (C55, C188 or C131)
  • Steel Engineering bush chains (S131 or S188)
  • Hollow pin conveyor chain (3"P x 6lb - 12"P x 36lb )
  • Solid pin conveyor chain  (3"P x 7.5lb - 12"P x 60lb)
CONTACT US FOR MORE INFORMATION

HSP Flyer HSP chain.pdf (495 KB)




Name Chain No. Pitch Roller Diameter Width between inner plates Pin Diameter Pin Length Pin Length Plate Thickness Average Tensile Strength Inner Plate Depth Enquire
P d1 max b1 min d2 max L max Lc max T max Qo h2 max
mm mm mm mm mm mm mm kN mm
S32 S32 29.21mm 11.43mm 15.88mm 4.45mm 26.70mm 28.80mm 1.80mm 21.6 13.20mm Enquire
S42 S42 34.93mm 14.27mm 19.05mm 7.00mm 34.30mm 37.00mm 2.80mm 50.8 19.80mm Enquire
S45 S45 41.40mm 15.24mm 22.23mm 5.72mm 37.70mm 40.40mm 2.80mm 36.1 17.30mm Enquire
S52 S52 38.10mm 15.24mm 22.23mm 5.72mm 37.70mm 40.40mm 2.80mm 36.1 17.30mm Enquire
S55 S55 41.40mm 17.78mm 22.23mm 5.72mm 37.70mm 40.40mm 2.80mm 36.1 17.30mm Enquire
S62 S62 41.91mm 19.05mm 26.20mm 5.72mm 40.30mm 43.00mm 2.50mm 36.1 17.30mm Enquire
S77 S77 58.34mm 18.26mm 22.23mm 8.90mm 43.20mm 46.40mm 4.00mm 73.1 26.20mm Enquire
S88 S88 66.27mm 22.86mm 28.58mm 8.90mm 49.80mm 53.00mm 4.00mm 73.1 26.20mm Enquire
CA550 CA550 41.40mm 16.87mm 19.81mm 7.19mm 35.00mm 38.00mm 2.80mm 51.2 19.30mm Enquire
CA555 CA555 41.40mm 16.87mm 12.70mm 7.19mm 29.10mm 32.00mm 3.10mm 56.0 19.30mm Enquire
CA557 CA557 41.40mm 17.78mm 20.24mm 8.00mm 37.40mm 40.60mm 3.10mm 74.3 23.10mm Enquire
CA620 CA620 42.01mm 17.91mm 24.51mm 7.19mm 41.80mm 45.20mm 3.25mm 55.10 20.20mm Enquire
