06B (3/8 Pitch) British Standard Sprockets

There are 44 listings available, you are viewing 1—30.

1 | 2 | Next»

Name Pitch Outside Bore Hub Hub Duplex Duplex Duplex Triplex Triplex Triplex Enquire
Via Dp Dia Do d Dh L d Dh L d Dh L
8 teeth 24.89mm 28.00mm 8mm 15mm 22mm 8mm 15mm 22mm 8mm 15mm 32mm Enquire
9 teeth 27.85mm 31.00mm 8mm 18mm 22mm 8mm 18mm 22mm 8mm 18mm 32mm Enquire
10 teeth 30.82mm 34.00mm 8mm 20mm 22mm 8mm 20mm 22mm 10mm 20mm 32mm Enquire
11 teeth 33.80mm 37.00mm 8mm 22mm 25mm 10mm 22mm 25mm 12mm 22mm 35mm Enquire
12 teeth 36.80mm 40.00mm 8mm 25mm 25mm 10mm 25mm 25mm 12mm 25mm 35mm Enquire
13 teeth 39.80mm 43.00mm 10mm 28mm 25mm 10mm 28mm 25mm 12mm 28mm 35mm Enquire
14 teeth 42.80mm 46.30mm 10mm 31mm 25mm 10mm 31mm 25mm 12mm 31mm 35mm Enquire
15 teeth 45.81mm 49.30mm 10mm 34mm 25mm 10mm 34mm 25mm 12mm 34mm 35mm Enquire
16 teeth 48.82mm 52.30mm 10mm 37mm 28mm 12mm 37mm 30mm 12mm 37mm 35mm Enquire
17 teeth 51.83mm 55.30mm 10mm 40mm 28mm 12mm 40mm 30mm 12mm 40mm 35mm Enquire
18 teeth 54.85mm 58.30mm 10mm 43mm 28mm 12mm 43mm 30mm 12mm 43mm 35mm Enquire
19 teeth 57.87mm 61.30mm 10mm 45mm 28mm 12mm 46mm 30mm 12mm 46mm 35mm Enquire
20 teeth 60.89mm 64.30mm 10mm 46mm 28mm 12mm 49mm 30mm 12mm 49mm 35mm Enquire
21 teeth 63.91mm 68.00mm 12mm 48mm 28mm 16mm 52mm 30mm 16mm 52mm 40mm Enquire
22 teeth 66.93mm 71.00mm 12mm 50mm 28mm 16mm 55mm 30mm 16mm 55mm 40mm Enquire
23 teeth 69.95mm 73.50mm 12mm 52mm 28mm 16mm 58mm 30mm 16mm 58mm 40mm Enquire
24 teeth 72.97mm 77.00mm 12mm 54mm 28mm 16mm 61mm 30mm 16mm 61mm 40mm Enquire
25 teeth 76.00mm 80.00mm 12mm 57mm 28mm 16mm 64mm 30mm 16mm 64mm 40mm Enquire
26 teeth 79.02mm 83.00mm 12mm 60mm 28mm 16mm 67mm 30mm 16mm 67mm 40mm Enquire
27 teeth 82.04mm 86.00mm 12mm 60mm 28mm 16mm 70mm 30mm 16mm 70mm 40mm Enquire
28 teeth 85.07mm 89.00mm 12mm 60mm 28mm 16mm 73mm 30mm 16mm 73mm 40mm Enquire
29 teeth 88.09mm 92.00mm 12mm 60mm 28mm 16mm 76mm 30mm 16mm 76mm 40mm Enquire
30 teeth 91.12mm 94.70mm 12mm 60mm 28mm 16mm 79mm 30mm 16mm 79mm 40mm Enquire
31 teeth 94.15mm 98.30mm 14mm 65mm 30mm 16mm 80mm 30mm 16mm 80mm 40mm Enquire
32 teeth 97.17mm 101.30mm 14mm 65mm 30mm 16mm 80mm 30mm 16mm 80mm 40mm Enquire
33 teeth 100.20mm 104.30mm 14mm 65mm 30mm 16mm 80mm 30mm 16mm 80mm 40mm Enquire
34 teeth 103.23mm 107.30mm 14mm 65mm 30mm 16mm 80mm 30mm 16mm 85mm 40mm Enquire
35 teeth 106.26mm 110.40mm 14mm 65mm 30mm 16mm 80mm 30mm 16mm 85mm 40mm Enquire
36 teeth 109.29mm 113.40mm 14mm 70mm 30mm 16mm 90mm 30mm 16mm 90mm 40mm Enquire
37 teeth 112.32mm 116.40mm 14mm 70mm 30mm 16mm 90mm 30mm 16mm 90mm 40mm Enquire

There are 44 listings available, you are viewing 1—30.

1 | 2 | Next»
